Aruba 6300F 24G 4SFP56 Sw
Aruba 6300F 24G 4SFP56 Sw

Aruba 6300F 24G 4SFP56 Sw (JL668A)

Marka : HPE Aruba
Fiyat : $7,252.00  + KDV
KDV Dahil : ₺331.314,29

Not: Ürün Görselleri üretici web sitesinden alınmıştır,

Lütfen Stok Sorunuz ve Fiyat teklifi isteyiniz.

HPE Aruba Networking CX 6300F 24‑port 1GbE and 4‑port SFP56 Switch

Power consumptionIdle: 49W
100% Traffic Rate: 63W

Input voltageFixed PSU: 100V‑120V/200V‑240V

Ports24-port 10/100/1000 BaseT ports

4x 1G/10G/25G/50G* SFP ports;

Supports PoE Standards IEEE 802.3af, 802.3at;

1x USB‑C Console Port;
1x OOBM port;
1x USB Type A Host port

Notes:
*50G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which requires QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports.

Latency1Gbps: 2.28μSec,
10Gbps: 1.46μSec,
25Gbps: 1.90μSec,
50Gbps: 3.49μSec

Switching capacity448 Gbps

Stacking capabilitiesUp to 10 switches per stack

NOTE: CX 6300L switches only stack with other CX 6300L switches

Throughput334 Mpps

Memory and processorQuad Core Arm Cortex™ A72 @ 1.8GHz
8 GB DDR4, 32 GB eMMC

8 MB, 16 MB, or 32 MB Shared Packet Buffer Memory, depending on model and configuration

Management featuresHPE Aruba Networking Central Network Management
HPE Aruba Networking Management Software (AirWave)
HPE Aruba Networking Switch Multi-Edit Software
Command-line interface
SNMP v2c/v3
RMON

WarrantyLimited lifetime warranty. See the warranty duration.

Detailed product descriptionCX 6300F 24-port 1 GbE and 4-port SFP56 switch
Includes Non-Pluggable, Internal PSU behind Sheetmetal Chassis Frame
Includes Non-Pluggable, Internal Fans behind Sheetmetal Chassis Frame
Min=0 \ Max = 4 SFP/SFP+/SFP28/SFP56 1/10/25/50 G Transceiver
1U - Height

Weight4.36 kg (9.61 lbs)

Dimensions4.4 x 44.2 x 32.7 cm (1.73 x 17.4 x 12.9 in)
